2KW Battery Cell Auto Sorting Machine Lithium Ion Battery Pack Assembly Line

Contact Now

2KW Battery Cell Auto Sorting Machine

Advanced lithium ion battery pack assembly line for efficient prismatic aluminum shell cell sorting and testing.

Key Features

Simple commissioning and easy-to-understand operation
Manual battery pack placement into mold for comprehensive pairing inspection
Manual core piling and feed assembly line operation
Automatic hand inhalation capability for 30 thickness cores (30PCS capacity)

Technical Specifications

Product Name	Prism aluminum shell cell sorting machine
Input Power	AC220V 50HZ 2KW
Usage	Prism core test Analyzer
Air Pressure	0.4-0.8Mpa, No water, no impurities
IR Tester	HK3560
Optional IR Tester	HIOKI3561/HIOKI3562/HK3561
Control Device	PLC touch screen control
Run Power	750W Servo electric
Cell Range	L50-200MM W15-50MM H60-200MM
Productivity	Approximately 2000PCS/H
Voltage Setting	0.00000V-6.0000V
Internal Resistance Setting	000.00mΩ-999.99mΩ
Certification	ISO9001
Channel	4OK,1NG
Test Data	Store with U disk
Communication Interface	RS485
Test Mode	4-wire system
Test Pin	DZ100-214A30G
Dimensions	L2070MMW1120MMH1710MM
Weight	Approximately 350KG

Support & Warranty

After-sales Service: Engineers available to service machinery overseas, Video technical support, Free spare parts, Online support
Warranty: 2 Years
